- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Smart-UPS Ultra
- Packaged Quantity
- 1 / Pack
- Product Type
- Double Conversion Online UPS
With Smart-UPS™ Ultra you can put up to 8000W of power protection in places never before possible. Make installation effortless with a 8kW UPS that is 30% smaller and lighter than any comparable UPS. The auto-rotating touch screen display makes switching between horizontal and vertical mounting options instantaneous. EcoStruxure Ready Smart-UPS provides visibility anywhere, anytime. Standard warranty, 5 years repair or replace.
- Warranty
- Limited Warranty
- 5 Year
- Additional Warranty Information
5 years repair or replace
- Technical Information
- Receptacle Type
- NEMA L6-20R
- NEMA L6-30R
- Receptacle Detail
- 2 x NEMA L6-20R
- 2 x NEMA L6-30R
- Features
- Audible Alarm
- Power Description
- Load Capacity (VA)
- 8000 VA
- Load Capacity (Watt)
- 8000 W
- Input Voltage
- 230 V AC
- Input Frequency
- 50 Hz
- 60 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Waveform Type
- Sine Wave
- Display & Graphics
- Display
- LCD
- Management
- Network Management
- Network Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- No
- EPO Port
- Yes
- Battery Information
- DC System Voltage
- 180 V DC
- Battery Chemistry
- Lithium Ion (Li-Ion)
- Typical Battery Recharge Time
- 1.50 Hour
- Environmental Conditions
- Minimum Operating Temperature
- 32°F (0°C)
- Maximum Operating Temperature
- 104°F (40°C)
- Storage Temperature
- 5°F (-15°C) - 113°F (45°C)
- Maximum Operating Elevation
- 10000 ft
- Maximum Storage Elevation
- 50000 ft
- Storage Relative Humidity
- 0% - 95%
- Sound Emission
- 55 dB
- Physical Characteristics
- Color Family
- Multicolor
- Product Color
- Silver
- Gray
- Height
- 17"
- Width
- 28.8"
- Depth
- 6.9"
- Form Factor
- Rack/Tower
- Miscellaneous
- Package Contents
- Smart-UPS Ultra On-Line 8000VA Rack/tower UPS
- RJ45 Cable
- Certifications & Standards
UL 1778
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- RoHS
- REACH
- Green Premium
- EU RoHS
- China RoHS
- ENERGY STAR 2.0
- Country of Origin
- Philippines
