- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Line
- Nexus
- Product Series
- 5500
- Product Type
- Layer 3 Switch
Today's data centers are increasingly filled with dense rack-mount and blade servers that host powerful multicore processors. The rapid increase in in-rack computing density and the increasing use of virtualization software combine to accelerate the demand for 10 Gigabit Ethernet and consolidated I/O: applications for which the Cisco Nexus® 5000 Series Switches are an excellent match. With low latency and choice of front-to-back or back-to-front cooling, copper or fiber access ports, and rear-facing data ports, the Cisco Nexus 5000 Series is designed for a broad range of physical, virtual, storage access, and high-performance computing environments, thus giving customers the flexibility to meet and scale their data center requirements in a gradual manner and at a pace that aligns with their business objectives.
- Warranty
- Limited Warranty
- 1 Year
- Interfaces/Ports
- Total Number of Network Ports
- 32
- Token Ring Port
- No
- LRE Port
- No
- Bypass
- No
- Modular
- No
- Management Port
- Yes
- USB
- No
- Stack Port
- No
- Number of Network (RJ-45) Ports
- 32
- Media & Performance
- Media Type Supported
- Twisted Pair
- Ethernet Technology
- 10 Gigabit Ethernet
- Network Technology
- 10GBase-T
- I/O Expansions
- Total Number of Expansion Slots
- 19.0
- Expansion Slot Type
- SFP+
- Shared SFP Slot
- No
- Number of SFP+ Slots
- 16
- Network & Communication
- Layer Supported
- 3
- Management & Protocols
- Manageable
- Yes
- Management
- SNMP v1, v2, v3
- RMON
- Telnet
- CLI
- QoS
- VLAN
- MIB
- DHCP
- Web Based Management
- Power Description
- PoE (RJ-45) Port
- No
- Power Source
- Power Supply
- Redundant Power Supply Supported
- Yes
- Physical Characteristics
- Compatible Rack Unit
- 2U
- Form Factor
- Rack-mountable
- Height
- 3.5"
- Width
- 17.3"
- Depth
- 29.5"
- Weight (Approximate)
- 47.50 lb
- Miscellaneous
- Package Contents
- Nexus 5596T 2RU, 2PS/4Fans, 32x10GT/16xSFP+ Fixed Ports
- 2 x 1100W AC Power Supplies
- 4 x Fan Trays
- 3 x Expansion Slots
- Certifications & Standards
- CE Markings
- 2004/108/EC
- 2006/95/EC
Safety:
- UL 60950-1 Second Edition
- CAN/CSA-C22.2 No. 60950-1 Second Edition
- EN 60950-1 Second Edition
- IEC 60950-1 Second Edition
- AS/NZS 60950-1
- GB4943
Emissions:
- 47CFR Part 15 (CFR 47) Class A
- AS/NZS CISPR22 Class A
- CISPR22 Class A
- EN55022 Class A
- ICES003 Class A
- VCCI Class A
- EN61000-3-2
- EN61000-3-3
- KN22 Class A
- CNS13438 Class A
Immunity:
- EN55024
- CISPR24
- EN300386
- KN 61000-4 series
IEEE Standards:
- 802.3
- 802.1D
- 802.1Q
- 802.3x
- 802.3ad
- 802.1w
- 802.3ae
- 802.1s
- 801.1p
- 802.1Qaz
- 802.1Qbb
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
