The 750VA UPS from V7 is a backup power source for desktop computers, network workstations and other professional and consumer electronic devices. The UPS is Energy Star Certified, ensuring maximum efficiency and is equipped with 10 Outlets (5 surge only and 5 with battery backup), for a consistent flow of electricity to help prevent costly equipment failure and data loss during power failures or other power issues. The convenient, compact desktop design is quick and easy to deploy, plus it features top facing outlets for fast deployment. Additionally, the UPS has USB connectivity to allow for additional configuration and control, plus audio and visual alarms for immediate warning of battery, load or other issues.
- General Information
- Manufacturer
- V7
- Manufacturer Website Address
- http://www.v7-world.com
- Brand Name
- V7
- Product Type
- Standby UPS
- Warranty
- Limited Warranty
- 3 Year
- Additional Warranty Information
- 1 Year Battery
- Technical Information
- Receptacle Detail
- 10
- Number of Battery & Surge Outlets
- 5
- Number of Surge-only Outlets
- 5
- Dataline Protection
- RJ-11
- RJ-45
- Cord Length
- 6 ft
- Transfer Time
- 10 ms
- Application/Usage
- Computer
- Power Description
- Load Capacity (VA)
- 750 VA
- Load Capacity (Watt)
- 450 W
- Input Voltage
- 120 V AC
- Waveform Type
- Simulated Sine Wave
- Surge Energy Rating
- 632 J
- Management
- Alarm
- On Battery
- Low Battery
- Overload
- Site Wiring Fault
- Controls/Indicators
- Status Indicators
LED status light:
- AC Mode (Green)
- Battery (Flashing Yellow)
- Fault (Red)
- AC Mode
- Battery mode
- Load Level
- Battery Level
- Input Voltage
- Output Voltage
- Overload, Fault
- Low Battery
- Interfaces/Ports
- USB
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- DC System Voltage
- 12 V DC
- Battery Characteristics
- Sealed
- Battery Chemistry
- Lead Acid
- Battery Capacity
- 5000 mAh
- Backup/Run Time (Full Load)
- 30 Second
- Backup/Run Time (Half Load)
- 5.50 Minute
- Typical Battery Recharge Time
- 8 Hour
- Environmental Conditions
- Maximum Operating Temperature
- 104°F (40°C)
- Sound Emission
- 40 dB
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Height
- 3.7"
- Width
- 6.2"
- Depth
- 12"
- Form Factor
- Desktop
- Weight (Approximate)
- 0.14 oz
- Miscellaneous
- Package Contents
- UPS 750VA Desktop with 10 Outlets, Touch LCD (UPS1DT750-1N)
- Setup Guide
- Warranty
- Certifications & Standards
- FCC
- TÜV
- Energy Star
- Yes
- Country of Origin
- Taiwan
- Environmentally Friendly
- Yes
